Gang Rip Blades
Gang Rip Blades
Regular price
$0.00 USD
Regular price
Sale price
$0.00 USD
Unit price
per
Couldn't load pickup availability
Blades are designed for Domestic and European multi-tip machines. Offered in a variety of kerfs and tooth counts to suit many unique requirements. Other rip blades can me modified to fit your machine.
| Part# | Dia | Tooth | Grind | Plate | Kerf | Bore | |
|---|---|---|---|---|---|---|---|
| GR1030 | 10" | 30T | 20ST | .095 | .165 | 70mm | (2)20x10 keyways |
| GR1040T-3 | 10" | 40T | 15TCG | .085 | .125 | 3" | 3 pinholes |
| GR1040T-4 | 10" | 40T | 15TCG | .085 | .125 | 4 3/16" | 3 pinholes |
| GR1224-125 | 12" | 24T | 20ST | .085 | .125 | 70mm | (2)20x10 keyways |
| GR1224-145 | 12" | 24T | 20ST | .095 | .145 | 70mm | (2)20x10 keyways |
| R1224-134 | 12" | 24T | 20ST | .085 | .125 | 1 3/4" | |
| GR1224-134 | 12" | 24T | 20ST | .095 | .145 | 1 3/4" | |
| GR1224-318 | 12" | 24T | 20TCG | .095 | .135 | 3.1/8" | |
| GR1228 | 12" | 28T | 20ST | .110 | .160 | 80mm | (2)20x5+6 pinholes |
| GR1230-134 | 12" | 30T | 20ST | .134 | .184 | 1 3/4" |
